M.2
80GB ~ 640GB
M.2 (S80) 3IE6-P
Features
- SATA III solution for industrial field
- High IOPS
- AES-256bits encryption
- Excellent random performance
- End to end data path protection
- iData Guard for abnormal power failure
- Supports TRIM/NCQ/SMART
- Support iSLC technology
Innodisk M.2 (S80) 3IE6-P is SATA III 6Gb/s solid state disk, which delivers excellent performance, especially in random data transfer rate, and which offers reliability making it the ideal solution for a variety of applications, including embedded system, industrial computing, and enterprise field. M.2 (S80) 3IE6-P not only performs unmatched performance, but also designed with Innodisk owned technical knowhow to ensure the data integrity and highest levels of reliability.
Innodisk M.2 (S80) 3IE6-P is designed for industrial field, and supports several standard features, including TRIM, NCQ, and S.M.A.R.T. In addition, Innodisk’s exclusive industrial-oriented firmware provides a flexible customization service, making it perfect for a variety of industrial applications.
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
iData Guard >
AES 256-bit DATA ENCRYPTION & TCG Opal 2.0 SUPPORT
Innodisk SSDs utilize AES 256-bit encryption, the US government’s standard for securing confidential data, while also supporting TCG Opal 2.0 for enhanced device management and user-friendly authentication.
AES & TCG Opal 2.0 >
iPower Guard – POWER PROTECTION TECHNOLOGY
iPower Guard is a proactive protection mechanism designed for environments with unstable power supplies. It provides further protection for SSDs during both startup and shutdown, preventing system performance issues caused by power instability.
iPower Guard >
ENSURING STABILITY IN EXTREME ENVIRONMENTS
The M.2 (S80) 3IE6-P supports a wide temperature range from -40°C to 85°C and incorporates a Dynamic Thermal Throttling mechanism for real-time SSD monitoring. When the temperature reaches a critical threshold, it automatically issues commands to smoothly reduce read and write speeds, maintaining operational stability.
Write Protect – SAFEGUARDING DATA SECURITY
With Innodisk SSD’s built-in write protection technology, users can utilize the read-only function to safeguard critical data within flash storage devices, preventing unauthorized modification or malicious use.
Write Protect >
Ultra iSLC
The M.2 (S80) 3IE6-P, featuring BiCS5 112-layer 3D TLC NAND Flash and Innodisk's exclusive Ultra iSLC Technology, achieves an industry-leading 100K P/E cycle. This advancement extends the device lifespan by 33 times compared to conventional 3D TLC NAND Flash.
Ultra iSLC >
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
EMPOWERING HIGH-SPEED NETWORKS FOR TELECOM GIANTS
In today's telecommunications landscape, the demand for high-speed network transmissions has reached unprecedented levels, and this surge brings forth a series of intricate challenges that demand immediate attention.
規格表
| Model Name | M.2 (S80) 3IE6-P |
|---|---|
| Flash Type | iSLC (3D TLC) |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | M.2 2280 B+M Key |
| Capacity | 80GB ~ 640GB |
| Sequential R / W (MB/sec, max.) | 490 / 490 |
| P/E Cycle | 30,000 |
| TBW (Max.) | 12,500 |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 2.6W |
| Max. Channels | 4 |
| External DRAM Buffer | Y |
| Feature | AES, TCG Opal 2.0, H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 22.0 x 80.0 x 1.35 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | 1500G@0.5ms |
| MTBF | >3 million hours |
| Warranty | 5 Years |
產品料號
Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
20GB | ||
40GB | ||
80GB | ||
160GB | ||
320GB | ||
640GB |
