mSATA
8GB ~ 512GB
mSATA 3ME3
Features
- SATA 6Gb/s interface
- iSMART disk health monitoring
- Intelligent error recovery system
- Excellent data transfer speed
- Zero mechanical interference
- Anti-vibration mechanical design
- JEDEC standard MO-300 dimension
Innodisk mSATA 3ME3 is designed with mSATA form factor by MO-300/MO-300B which established by JEDEC, and support SATA III standard (6.0Gb/s) with excellent performance. Regarding of mechanical interference, Innodisk mSATA 3ME3 absolutely replaces the traditional hard disk and makes personal computer, in any field, smaller and easier.
Innodisk mSATA 3ME3 effectively reduces the booting time of operation system and the power consumption is less than hard disk drive HDD), and complies with ATA protocol, no additional drives are required, and can be configured as a boot device or data storage device.
Write Protect – SAFEGUARDING DATA SECURITY
With Innodisk SSD’s built-in write protection technology, users can utilize the read-only function to safeguard critical data within flash storage devices, preventing unauthorized modification or malicious use.
Write Protect >
iData Guard – DATA PROTECTION TECHNOLOGY
iData Guard enables the immediate sending of a command in the event of a sudden power failure, interrupting read and write commands from the system and ensuring that the last command can be completed. This preserves data integrity on the SSD, protecting data security.
iData Guard >
AES 256-bit DATA ENCRYPTION & TCG Opal 2.0 SUPPORT
Innodisk SSDs utilize AES 256-bit encryption, the US government’s standard for securing confidential data, while also supporting TCG Opal 2.0 for enhanced device management and user-friendly authentication.
AES & TCG Opal 2.0 >
iPower Guard – POWER PROTECTION TECHNOLOGY
iPower Guard is a proactive protection mechanism designed for environments with unstable power supplies. It provides further protection for SSDs during both startup and shutdown, preventing system performance issues caused by power instability.
iPower Guard >
ENSURING STABILITY IN EXTREME ENVIRONMENTS
The mSATA 3ME3 supports a wide temperature range from -40°C to 85°C and incorporates a Dynamic Thermal Throttling mechanism for real-time SSD monitoring. When the temperature reaches a critical threshold, it automatically issues commands to smoothly reduce read and write speeds, maintaining operational stability.
IMPLEMENTED WITH SUCCESS IN DYNAMIC ENVIRONMENTS
EMPOWERING HIGH-SPEED NETWORKS FOR TELECOM GIANTS
In today's telecommunications landscape, the demand for high-speed network transmissions has reached unprecedented levels, and this surge brings forth a series of intricate challenges that demand immediate attention.
規格表
| Model Name | mSATA 3ME3 |
|---|---|
| Flash Type | MLC |
| Interface | SATA III 6.0 Gb/s |
| Form Factor | MO-300 |
| Capacity | 8GB ~ 512GB |
| Sequential R / W (MB/sec, max.) | 400 / 200 |
| P/E Cycle | 3,000 |
| TBW (Max.) | 153 |
| Storage Temperature | -55°C ~ 95°C |
| Max. Power Consumption | 1.4W |
| Max. Channels | 4 |
| External DRAM Buffer | N |
| Feature | H/W Write Protect, S.M.A.R.T. |
| Dimension (W x L x H/mm) | 29.8 x 50.8 x 3.3 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | 1500G@0.5ms |
| MTBF | >3 million hours |
| Warranty | 2 Years |
產品料號
| Operating Temperature | Standard Grade (0°C ~ 70°C) | Industrial Grade (-40°C ~ 85°C) |
20GB | ||
40GB | ||
80GB | ||
160GB | ||
320GB | ||
| 640GB |
